Motor Power: 37 kW
Maximum Output: 150 kg/h
| Equipment Name: | φ75mm 16D/20D Rubber Extruder |
| Equipment Model: | E2-75-16D-03-00 |
| Equipment Application: | Extrudes rubber and provides mixing and plasticizing functions; used in conjunction with a die head for extrusion molding. |
| Overall Dimensions: | 2650mm × 2130mm × 2262mm (Length × Width × Height) |
| Extrusion System | |
| Feeding Method: | Active feeding driven by a feeding motor and side pressure roller (sprocket drive) |
| Feeding Motor: | Geared motor (Cheng Bang) CH50-3700 (15-60) |
| Pressure Control: | Equipped with a pressure sensor, adjustable pressure protection value 0-50MPA |
| Extruder Mounting: | Stationary |
| Length-to-Diameter Ratio: | 16:01 |
| Screw Diameter: | 75mm |
| Screw Speed: | 5-55 r/min |
| Maximum Output: | Approximately 150 kg/h (under no pressure) |
| Temperature Control System | |
| Heating Zones/Power: | 3kw × 4 |
| Cooling Zones: | 1 zone (side pressure roller) |
| Circulating Water Pump Brand: | Olanque |
| Cooling Water Pressure: | 0.15-2 KG/cm² |
| Temperature Control Accuracy: | ±1℃ |
| Drive System | |
| Screw and Gearbox Connection: | Spline connection |
| Motor and Gearbox Drive: | Belt drive |
| Hardened Gear Reducer Model: | ZLYJ224-20-1 |
| Motor Power: | Motor [225S-4]-B3 (37KW) |
| Total Equipment Power: | Approximately 55KW |
| Speed Control Method: | Variable frequency speed control |
